Frame | 6061 alloy, hydroformed T6 aluminium, multi-butted, Single Chainring(SCR), tapered headtube, internal cable routing with BBX63, chainstayPost Mount dropouts and 12mm x 148mm Boost dropouts |
Fork | RockShox Recon RL 29in, 120mm travel, 42mm offset, Solo Air, Fast Blackcoating, adjustable rebound, tapered alloy steerer, 110mm x 15mm Boost,Maxle Lite |
Headset | FSA No. 57B Orbit ZS, 1 1/2in lower and 1 1/8in upper caged bearings |
Rear Hub | Alloy, double sealed cartridge bearings, 12mm x 148mm Boost thru-axle,32 hole |
Front Hub | Alloy, double sealed cartridge bearings, 15mm x 110mm Boost thru-axle,32 hole |
Spokes | DT Swiss Champion 2.0mm, black stainless, brass nipples |
Rims | WTB ST i27 TCS 2.0 System, pinned joint, tubeless ready, 32 hole |
Tyres | Maxxis Ardent 29in x 2.4in EXO Dual Compound, 60TPI, tanwall |
Shift Levers | SRAM SX Eagle |
Rear Derailleur | SRAM SX Eagle, 12 speed |
Cassette | SRAM PG-1210 Eagle, 11-50T, 12 speed |
Chain | SRAM SX Eagle, 12 speed |
Crankset | SRAM X1 Eagle, X-SYNC 2, Direct Mount 32T, DUB, 170mm, Boost 12 speed |
Bottom Bracket | SRAM DUB, BSA, 73mm |
Seatpost | KS 900i, 30.9mm (S 125mm travel, M-XL 150mm travel), Southpaw remote lever |
Seat | Whyte Custom |
Bar | Whyte 6061 alloy, 15mm rise, 31.8mm, 780mm wide |
Stem | Whyte alloy, 45mm extension |
Grips | Whyte Lock-on Enduro |
Front Brake | Tektro HD-M535, four piston, 2.3mm gauge 180mm disc |
Rear Brake | Tektro HD-M535, four piston, 2.3mm gauge 180mm disc, internal routing |
Pedals | Click here to choose an upgrade pedal |
