Look cool riding with the other kids or keep up with mum and dad on the trail... the Hidden Canyon is a great little bike for a juniour rider.
Look cool riding with the other kids or keep up with mum and dad on the trail... the Hidden Canyon is a great little bike for a juniour rider.
Marin

Marin Hidden Canyon 20 Junior Mountain Bike - Teal/ Pink

£479.00
Pre-Order

With Pre-Order, you can purchase the latest items added to our store in advance of them arriving with us.

Your Pre-Order is prioritised (at no additional charge); meaning that as soon as the product arrives with us, we can wrap it straight back up; ready for collection via Click & Collect or despatch to you — it often never even hits the stock room shelves!

Pre-Launch

With Pre-Launch, the date when we expect to receive the product ourselves is still a little too hazy to be confident in accepting Pre-Orders.

So, instead, you can submit your email address against the item you are interested in and we will email you as soon as stock arrives on the system.

Estimated Delivery & Collection Dates

Estimated Delivery & Collection Dates are given on Pre-Order and Pre-Launch products. They are for indication purposes only and can change at any time without notice.

The dates we provide are based on indications given by our suppliers. Whenever we get updated information from our suppliers we will endeavour to update the Estimated Delivery & Collection Dates provided on product pages.

We estimate this will be ready for despatch to you or collection via Click & Collect on Undetermined

Marin Hidden Canyon 20 Junior Mountain Bike - Teal/ Pink

Season:2023

Brand:Marin

Code:733949

FUN!

The Hidden Canyon 20” is built to get kids hooked on riding with quality components and fun graphics that will last for years of neighborhood and bike park service.

  • Lightweight Series 1 6061 aluminum frames with replaceable derailleur hangers and disc brakes with size-appropriate brake levers for comfort and control.
  • The durable Shimano 7-speed drivetrain has the gear choices kid need to tackle trails in an easy to master package with a single front chainring and intuitive twist shifter.
Technical Information

SPECIFICATIONS

FRAME

Series 1 6061 Aluminum, 20” Wheels, IS Seatstay Disc Mounts, 135mm Dropouts

FORKS

Steel Rigid Fork, 100mm Spacing, QR Lever

RIMS

Marin, Double Wall Alloy

HUB, REAR

Formula, 32H

HUB, FRONT

Formula, 32H

SPOKE, NIPPLES

14g Stainless Steel

TIRES

Multi Surface, 20”x2.125”

DERAILLEUR, REAR

Shimano Tourney, 7-Speed

SHIFT LEVER

Shimano Revo Twist 1x7-Speed

CRANKSET

Forged Alloy, 36T, 140mm, Ring Guard

BOTTOM BRACKET

Sealed Cartridge Bearings, Square Taper

CHAIN

KMC Z50

CASSETTE

Shimano HG20, 12-28T

BRAKE, FRONT

Power CX7 Mechanical Disc, Shimano Pad Compatible, 160mm Rotor

BRAKE, REAR

Power CX7 Mechanical Disc, Shimano Pad Compatible, 160mm Rotor

BRAKE LEVERS

Kids Specific Short Reach Alloy

HANDLEBAR

Marin Riser, 30mm Rise, 590mm Width

STEM

Marin Alloy, 60mm

GRIPS

Marin Dual Density

HEADSET

FSA, Threaded

SEATPOST

Marin Alloy, 27.2mm

SADDLE

Marin Kids MTB

PEDALS

Kids Specific Nylon
Sizing Information

Geometry

Hidden Canyon geometry diagram
ONE SIZE
Stack439.39
Reach297.66
Headtube Angle70°
Headtube Length105
Seattube Angle73°
Seattube Length308
Toptube Effective432
BB Height232
BB Drop25
Chainstay380
Wheelbase862.79
Standover Height511.66
Fork Offset33
Seatpost Diameter27.2
Handlebar Width590
Stem Length45
Crank Length140

All lengths in millimeters
