FRAME
FACT 11m carbon chassis and rear-end, asymmetrical design, 29 Trail Geometry, SWAT™ Door integration, flip chip Head Tube/Bottom Bracket adjustment, threaded BB, fully enclosed internal cable routing, 12x148mm dropouts, sealed cartridge bearing pivots, replaceable derailleur hanger, 130mm of travel
SEAT BINDER
Alloy, 38.6
SWAT
SWAT™ Door integration
REAR SHOCK
RockShox Deluxe Ultimate, Rx Trail Tune, 190x45
FORK
RockShox Pike Ultimate, Charger 3 RC2 Damper w/Buttercups, 15x110mm axle, 44mm offset, 140mm of travel
STEM
Alloy Trail Stem, 35mm bar bore
HANDLEBARS
Specialized Trail, 7050 alloy, 8-degree backsweep, 6-degree upsweep, 30mm rise, 800mm, 35mm clamp
SADDLE
Bridge Comp, Hollow Cr-mo rails, 155/143mm
SEATPOST
OneUp, Dropper Post-V2, MMX lever, 34.9 (S1:120mm, S2/S3:150mm, S4: 180mm, S5/S6: 210mm)
Grips
Deity Lockjaw
FRONT BRAKE
SRAM Code Silver Stealth, 4-piston caliper, hydraulic disc, 200mm
REAR BRAKE
SRAM Code Silver Stealth, 4-piston caliper, hydraulic disc, 180mm
REAR DERAILLEUR
SRAM GX Eagle Transmission Cassette, 12spd, 10-52t
SHIFT LEVERS
SRAM AXS POD Controller
CHAIN
SRAM GX Eagle Transmission Flattop Chain
CRANKSET
SRAM GX Eagle Crankset, Alloy, Integrated Guard, 55mm Chainline, S1:165mm, S2-S5: 170mm, S6: 175mm
CHAINRINGS
32T
RIMS
Roval Traverse 29F/27.5R Alloy, 30mm inner width, hand-built, 2Bliss Ready
FRONT HUB
Roval, sealed cartridge bearings, 15x110mm spacing, 28h
REAR HUB
Roval DT Swiss 370, Ratchet LN, SRAM XD driver body, 12mm thru-axle, 148mm spacing, 28h
SPOKES
DT Swiss Industry
FRONT TIRE
Butcher, GRID casing, GRIPTON® T9 compound, 29x2.3"
REAR TIRE
Purgatory, GRID casing, GRIPTON® T7 compound, 2Bliss Ready, 27.5x2.3"
INNER TUBES
Standard, Presta valve
